SMITH DUMP BOX AUGER SPREADER

SmithDumpBox
SmithDumpBox Smith Spreaders Smith Spreaders

Smith Metal Works of Newark introduced the next evolution of Dump Box Spreaders. Designed for Dump Bodies and Highway Department Dump Trucks, they are lightweight and easy to install through the coal chute. The simplistic design and easy installation make tackling those early or late ice storms no longer a challenge. Dual hydraulic motors and replacing the chain with an auger system leave minimum maintenance. Our auger design unloads evenly, maintaining the stability of the truck. All dump box auger spreaders include a galvanized screen.

Fits: Dump Trucks, Municipal Vehicles
Hopper Material: Stainless Steel

Please contact us for more information about this product.

Request a Quote


Share this product:

Smith Dump Box Auger Spreader Specifications


Smith Dump Box Auger Spreader Features

STANDARD FEATURES

  • Two hydraulic motors & 2 bearings.
  • Safety screen – same length as the truck box.
  • 7″ diameter auger with progressive flighting.
  • Fluid power motor (Eaton replacement).

Installation is made easy by two methods:

  • Through an existing coal tailgate door.
  • Cut to size as stated in service manual and use the supplied door plate.

Options & Accessories

  • The hydraulic discharge chute option is plumbed unto the box lift cylinder so that if the box needs to be raised to push material back towards the tailgate to continue the route or dump excess material, the chute goes up and out of the way. This eliminates the need to get out and manually raise the chute.
  • Sensor Motor. Ask your dealer for current pricing.

  • Structural steel construction with zinc prime & powder coated finish
  • interior body widths are 88″(EXT) & 87″(INT) and exterior width is 96″
  • Interior height is 72″ high
  • Floors are constructed of 10GA steel sheet with 3″ structural channel on 16″ centers
  • Posts are constructed of 12GA steel sheet; exterior posts are 5″ formed posts on 36″-48″ centers, Interior posts are 3″ structural channel on 16″ centers
  • Top rails are constructed of 3″ x 3″ x 1/8″ square steel tubing
  • Rear corner posts are constructed of 7GA steel
  • Roofs are constructed of 12GA steel with a 6″ peak
  • Lockable security-style doors with 3″ x 3″ supports
  • Standard 6″ steel ground rollers
