| Length (* Length includes 4' rear beaver tail and front bulkhead) | 15', 16', 18', 20' |
| Perimeter wall | 1-1/2" steel tubing |
| Expanded metal permanent- mount sides | 18" high |
| Structural channel long sills | 4" |
| Formed channel crossmembers 12" centers | 3" |
| Steel tubing and mesh bulkhead | 60" high 1-1/2" with 18" side returns and built-in 24" high storage box with lockable drop down door |
| Floor | 1/8" Diamond plate floor, including beaver tail |
| Expanded metal spring-assisted loading ramp | 72" long (92" wide) |
| D-Rings | 4 on floor per side (more optional) |
| Color | Primed and painted black (other colors available) |
| Rear beaver tail | 4' with 12" drop |
| LED light kit | 6" LED oval stop/turn/tail and reverse lights with marker and clearance |
